In this tutorial, you will learn how to implement a simple UI web dashboard in vanilla JavaScript that integrates with the Kaa IoT platform and provides a simple device management functionality. You will learn how to:
*
value in Valid Redirect URIs
for the development purpose. Remove *
in production.
*
value in Web Origins
for the development purpose. Remove *
in production.
Keycloak comes with a client-side JavaScript library that can be used to secure HTML5/JavaScript applications.
The library can be retrieved directly from the Keycloak server at https://auth.cloud.kaaiot.com/auth/js/keycloak.js
REST API endpoint.
The best practice is to load the JavaScript adapter programmatically directly from Keycloak Server as it will automatically be updated when you upgrade the server. Make sure you upgrade the adapter only after you have upgraded the server.
Let’s create a project folder and download the library into the file named keycloak.js
:
$ mkdir custom-dashboard-tutorial/
$ cd custom-dashboard-tutorial/
$ curl https://auth.cloud.kaaiot.com/auth/js/keycloak.js >> keycloak.js
Once the library is downloaded, go to the Keycloak administration page of the client (User management sidebar link in the Kaa Cloud UI -> Clients in the Keycloak sidebar -> select client with the kaa-frontend name -> Settings tab), click on the Installation tab, select Keycloak OIDC JSON for the Format Option, and then click the Download button.
The downloaded keycloak.json
file must be placed into the root project directory along with the keycloak.js
.
The keycloak.json
file contains Keycloak auth URL, information about realm, client ID, etc. Check it.
Your current project directory must look as follows:
custom-dashboard-tutorial/
|--- keycloak.js
|--- keycloak.json
Now let’s have fun with some coding :)
Create the index.html
HTML file in the project root and paste the below code into it:
<html lang="en">
<head>
<script src="keycloak.js"></script>
</head>
Hello, user! You are logged-in!
<script>
var keycloak = new Keycloak();
keycloak
.init({onLoad: 'login-required'})
.success(function() {
// render page visible for a logged in user
// renderApp(keycloak)
}).error(function () {
// log error
// renderError('Failed to initialize the Keycloak client');
});
</script>
</html>
Here we initialize the JavaScript adapter.
Pay attention to the passed {onLoad: 'login-required'}
option to the init
method.
login-required
will automatically authenticate the client if the user is logged in to the Keycloak or display the Keycloak login page if not.
Load to your web server index.html
, open it in a browser, and verify that you are immediately redirected to the Keycloak login page:
Enter your username/password and verify that you are redirected back to our web dashboard.
If the login process succeeds, the callback passed to the keycloak
’s success
method is called.
In the callback, we will render the application for the logged-in user.
However, if the login process fails, the callback passed to the keycloak
’s error
method is called. In the callback, we will notify the user about the error.
After the successful login process, the keycloak
variable authenticates the user’s access token that can be obtained next: keycloak.token
.
Now we can use the access token in subsequent requests to any Kaa platform microservice REST API specifying it in the Authorization
header: Authorization: bearer eyJhbGciOiJSUzI1NiIsInR5cCIg...
Check this section on REST API overview page to find out how to manually obtain and use a user access token in requests to the Kaa REST API.
Next, create the index.js
file in the project root.
This file will contain application rendering logic.
Firstly, we will implement the renderApp
method.
Here we call GET /api/v1/endpoints
REST API with the access token obtained by the Keycloak adapter.
This REST API endpoint returns all available endpoints for a requesting user.
var renderApp = (keycloak) => {
if (keycloak.token) {
const url = 'https://cloud.kaaiot.com/epr/api/v1/endpoints?include=metadata';
const req = new XMLHttpRequest();
req.open('GET', url, true);
req.setRequestHeader('Accept', 'application/json');
req.setRequestHeader('Authorization', `bearer ${keycloak.token}`);
req.onreadystatechange = function () {
if (req.readyState === 4) {
if (req.status === 200) {
renderEndpointTable(req.responseText);
} else {
renderError(`Failed to retrieve endpoints' metadata`);
}
}
};
req.send();
} else {
document.getElementById('container').innerHTML = `<button onclick="keycloak.login()">Login</button>`;
}
};
var renderError = (errorMessage) => {
document.getElementById('container').innerHTML = `<p style="color: red">${errorMessage}</p>`;
};
In the code above, if the access token is presented (keycloak.token
is not undefined
), it is used to retrieve endpoints.
Otherwise, a Login button is rendered.
Now, let’s implement the renderEndpointTable
method, which will render the retrieved from the previous step endpoints into an HTML table.
function renderEndpointTable(responseText) {
const response = JSON.parse(responseText);
let endpointRows = ``;
for (const endpointInfo of response.content) {
endpointRows = endpointRows + `
<tr class="endpoint">
<td class="endpointId">${endpointInfo.endpointId}</td>
<td>${endpointInfo.appVersion.name}</td>
<td><input class="location" type="text" value="${endpointInfo.metadata.location
|| ''}"></td>
</tr>`
}
document.getElementById('table').innerHTML = endpointRows;
document.getElementById('save-button').innerHTML =
'<button onclick="saveEndpointLocation(keycloak)">Save location</button>';
}
The table displays an endpoint ID, its application version, and an endpoint location
metadata field (you may want to introduce your own metadata field since the Kaa platform is agnostic to the endpoint metadata structure).
Let’s update index.html
with the HTML of the table and add some styles to prettify it.
<html lang="en">
<head>
<link rel="stylesheet" type="text/css" href="style.css">
<script src="keycloak.js"></script>
<script src="index.js"></script>
</head>
<body>
<div id="container">
<table>
<caption id="table-caption">My endpoints</caption>
<thead>
<tr>
<th>Endpoint ID</th>
<th>Application version</th>
<th>Location</th>
</tr>
</thead>
<tbody id="table">
</tbody>
</table>
</div>
</body>
<script>
var keycloak = new Keycloak();
keycloak.init({onLoad: 'login-required'}).success(function() {
renderApp(keycloak);
}).error(function () {
renderError('Failed to initialize Keycloak client');
});
</script>
</html>
Revisit the index.html
in a browser (log in if needed) and verify that endpoint data is successfully retrieved.
As you can see, there is no data in the Location column since none of the endpoints have the corresponding metadata field (in your case, it may be filled if endpoints do have such a metadata attribute). Jump below to change it.
Let’s expand our functionality to not only retrieving and displaying endpoint information but also updating it.
For that, go to the index.html
and add the <p>
tag above the closing </body>
tag:
...
<p id="save-button">
</p>
</body>
...
Add the saveEndpointLocation
method to the index.js
.
It sends an endpoint location entered by the user to the server using the [EPR REST API][epr put metadata key].
var saveEndpointLocation = (accessToken) => {
const endpointsInfo = document.getElementsByClassName('endpoint');
for (const endpointInfo of endpointsInfo) {
const endpointId = endpointInfo.getElementsByClassName('endpointId')[0].innerText;
const updatedLocation = endpointInfo.getElementsByClassName('location')[0].value;
// request execution
const url = `${baseKaaPlatformUrl}/epr/api/v1/endpoints/${endpointId}/metadata/location`;
const req = new XMLHttpRequest();
req.open('PUT', url, true);
req.setRequestHeader('Content-Type', 'application/json');
req.setRequestHeader('Authorization', `bearer ${accessToken}`);
req.send(JSON.stringify(updatedLocation));
}
};
Pay attention to the req.setRequestHeader('Authorization', 'bearer ${accessToken}');
line.
Here we initialize the Authorization
header with the user access token prefixed with the bearer
.
Add rendering of the ‘Save changes’ button under the renderEndpointTable
method invocation in the renderApp
method.
...
if (req.status === 200) {
renderEndpointTable(req.responseText);
// 'Save changes' button rendering
document.getElementById('save-button').innerHTML =
'<button onclick="saveEndpointLocation(keycloak.token)">Save changes</button>';
} else {
renderError(`Failed to retrieve endpoints' metadata`);
}
...
Revisit the index.html
file in the browser, enter any endpoint location you want, and click the ‘Save changes’ button.
It should save the entered location.
Refresh the page and verify that all the changes were saved.
Now you can use the same approach with the Authorization
header to communicate with any Kaa Platform REST API.
Refer to Kaa REST API authentication section to see how you can acquire on-demand access token using cURL.
